Резисторная сборка 4116R-001-103 10 кОм

Корпус dip16
Base Product Number 4116R->
California Prop 65 Warning Information
Circuit Type Isolated
ECCN EAR99
Height - Seated (Max) 0.185""(4.69mm)
HTSUS 8533.21.0060
Moisture Sensitivity Level (MSL) 1(Unlimited)
Mounting Type Through Hole
Number of Pins 16
Operating Temperature -55В°C ~ 125В°C
Package Tube
Package / Case 16-DIP(0.300"", 7.62mm)
Power Per Element 250mW
REACH Status REACH Unaffected
Resistor-Ratio-Drift 50ppm/В°C
RoHS Status RoHS non-compliant
Size / Dimension 0.865"" L x 0.300"" W(21.97mm x 7.62mm)
Supplier Device Package 16-DIP
Temperature Coefficient В±100ppm/В°C
Case Style Moulded
Circuit Designator ISOL
Maximum Operating Temperature +125°C
Minimum Operating Temperature -55°C
Number of Terminals 16
Package/Case DIP
Power Rating per Resistor 0.25W
Series 4100R
Termination Style Through Hole
Depth Tolerance (mm) ±0.25
ECCN (US) EAR99
EU RoHS Compliant with Exemption
HTS 8533.29.00.00
Maximum Operating Temperature (°C) 125
Minimum Operating Temperature (°C) -55
Mounting Through Hole
Package Shape Rectangular
Package Type DIP
Part Status Active
Power Rating per Resistor (W) 0.25(1/4)
Product Depth (mm) 7.87
Product Height (mm) 3.68
Product Length (mm) 21.97
Seated Plane Height (mm) 4.57
Technology Thick Film
Temperature Coefficient (ppm/°C) ±100
Temperature Range @ Derated Power (°C) 70 to 125
Terminal Pitch (mm) 2.54
Brand: Bourns
Circuit Type: Isolated
Factory Pack Quantity: Factory Pack Quantity: 25
Lead Spacing: 2.54 mm
Manufacturer: Bourns
Maximum Operating Temperature: +125 C
Minimum Operating Temperature: -55 C
Number of Pins: 16
Operating Temperature Range: -55 C to+125 C
Package / Case: DIP-16
Packaging: Tube
Power per Element: 2.25 W
Product Category: Resistor Networks & Arrays
Product Type: Resistor Networks & Arrays
Product: Networks
Subcategory: Resistors
Temperature Coefficient: 100 PPM/C
Termination Style: DIP
RoHS N
Диапазон рабочих температур 55 C to+125 C
Длина 27.05 mm
Категория продукта Резисторные сборки и массивы
Количество контактов 16
Максимальная рабочая температура +125 C
Минимальная рабочая температура 55 C
Подкатегория Resistors
Продукт Networks
Размер фабричной упаковки 25
Температурный коэффициент 100 PPM/C
Технология Power over Ethernet (PoE) 2.25 W
Тип выводов DIP
Тип продукта Resistor Networks Arrays
Тип цепи Isolated
Торговая марка Bourns
Упаковка / блок DIP-16
Шаг выводов 2.54 mm
Ширина 4.57 mm
Automotive No
ESD Protection Unknown
Military No
Operating Temperature - (??C) -55~125
Power Rating - (W) 2.25
Terminal Pitch - (mm) 2.54
